Flat cover(Side entry) single bag filter housing

SAM-2P // SAM-1P

This P type filter adopts a side-in and bottom-out method. The filter liquid medium is pressed or pumped into the filter barrel through the pressure in the pipeline. The liquid medium is filtered through the filter bag supported by the stainless steel plate punching support basket, producing an ideal The solid-liquid separation achieves the effect of filtering the liquid medium. Different filtration precision depends on different precision filter bags.

FEATURES:

● Good sealing effect, eliminating side leakage

● Cheap price and economical

● Convenient way to replacing filter bags and the operating cost is lower

● The installation and debugging are adjustable to adapt to the space requirements of specific applications.
